Precision Systems for
Critical Measurements
From remote field stations to industrial facilities, our data acquisition systems deliver the accuracy and reliability your research and operations demand.
Engineered for
Excellence
Every EED system is designed with a singular focus: capturing accurate data in challenging environments. We combine proven sensor technologies with innovative data processing to deliver insights you can trust.
Atmospheric &
Environmental Monitoring
Comprehensive weather stations, data acquisition systems, and sensors for atmospheric and environmental monitoring. Our systems capture critical data on weather patterns, air quality, soil conditions, and climate variables.
- Complete weather station systems
- Air quality & emissions sensors
- Soil moisture & temperature arrays
- Remote solar-powered stations
Process
Intelligence
Robust data acquisition for manufacturing, mining, and energy sectors. Our industrial systems are built to withstand harsh conditions while delivering the precision required for process optimization and safety.
- High-frequency vibration analysis
- Temperature & pressure monitoring
- Emissions & air quality tracking
- SCADA integration ready
Sigfox Loadcell
Junction Box
An intelligent IoT-enabled junction box that replaces traditional passive junction boxes with remote monitoring capabilities. Interfacing between Thames Side LA85/T85 load cells and the Promtek PK486A amplifier, this device transmits balance status data every 30 minutes via Sigfox to a ThingsBoard cloud dashboard while maintaining complete signal integrity.
Technical Architecture
- 4-channel load cell monitoring
- 30-minute transmission intervals
- Signal pass-through (preserves calibration)
- Dual power modes (10V/24V)
- IP65-rated enclosure
- ThingsBoard integration
Core Components
- STM32L431CC (ARM Cortex-M4)
- 4× INA126 amplifiers (G=5-10)
- LSM100A EVK (Sigfox RC1, 868 MHz)
- Thames Side LA85/T85 load cells
- Promtek PK486A amplifier
- DIN rail mount enclosure
Signal Processing
- Differential mV/V acquisition
- 12-bit ADC sampling
- High-impedance signal tapping
- Zero calibration impact
- Independent per-channel processing
- 3.3V internal regulation
Cloud Integration
- Real-time balance status
- Trend visualization graphs
- Configurable imbalance alerts
- Historical data export
- 12-byte Sigfox payload
- 48 messages/day capacity
Key Advantages
Agricultural
Science
Precision agriculture monitoring systems for crop management, irrigation optimization, and farm-level weather data. Our agricultural solutions help farmers make data-driven decisions to improve yields and reduce costs.
- Crop monitoring sensors
- Irrigation management systems
- Farm weather stations
- Grain storage monitoring (SiloSpi)
Ready to Specify
Your System?
Our team will work with you to design a data acquisition system that meets your exact requirements. From sensor selection to deployment, we're with you every step of the way.
